- Factory Options
- PAINT, SOLID
- ENGINE, VORTEC 6000 V8 SFI(300 HP [223.8 kW] @ 4400 rpm, 360 lb.-ft. [486.6 N-m] @ 4000 rpm)
- Safety
- Air bags, frontal, driver and right front passenger, includes Passenger Sensing System (Always use safety belts and proper child restraints, with air bags. Children are safer when properly secured in a rear seat. See the Owner's Manual for more safety information.)
- Exterior
- Paint, solid
- Bumper, front, chrome, with Gray lower
- Bumper, rear, chrome step, includes pad
- Air dam, Gray
- Wheel flares, front and rear
- Grille, color-keyed surround, with chrome accent bar
- Moldings, bodyside (Moldings are bright. Not available with (ZW9) Pickup bed delete)
- Fog lamps, front, halogen
- Lamps, dual cargo area lamps
- Glass, Solar-Ray deep tinted (all windows except light tinted glass on windshield) (With Extended Cab Models, includes rear window and rear quarter - With (C49) Defogger, rear-window, electric, includes light-tinted rear window.)
- Windows, rear quarter swing-out (Standard with Extended Cab Models only.)
- Wipers, intermittent, front wet-arm with pulse washers
- Interior
- Seats, rear bench, folding, 3-passenger (includes child seat top tether anchor) (Requires Extended Cab Models. - With Leather seat inserts, rear seat is vinyl.)
- Console, floor, includes storage compartment and dual cupholders
- Floor covering, color-keyed carpeting and rubberized vinyl floormats
- Steering column, Tilt-Wheel, adjustable, includes brake/transmission shift interlock
- Steering wheel, leather-wrapped rim, Black, steel sleeve, includes theft-deterrent locking feature
- Theft-deterrent system, PASSlock II
- Instrumentation, analog, includes speedometer, odometer with trip odometer, fuel level, voltmeter, engine temperature, oil pressure and tachometer
- Driver Information Center, includes trip odometer and message center (monitors numerous systems depending on vehicle equipment level including low fuel, turn signal "on", transmission temperature, and oil change notification) (With (UK3) Sound system feature, steering wheel mounted radio controls, includes trip and fuel information selections and programmable personalization features.)
- Warning tones, headlamp on, key-in-ignition, driver and passenger seat belt reminder, turn signal on
- Cruise control, electronic with set and resume speed, includes telltale in instrument panel cluster
- Windows, power, includes driver express-down
- Defogger, rear-window, electric
- Sound system feature, steering wheel mounted radio controls, Radio and Driver Information Center (DIC). Provides access to enhanced Driver Information Center (DIC) features and information.
- Cupholders, front (Also includes rear cupholders on Extended Cab Models.)
- Cigarette lighter, on instrument panel
- Power outlets, auxiliary, covered, 2 dash-mounted, 12-volt
- Mirror, inside rearview, electrochromic (light-sensitive auto dimming), 8-point compass and outside temperature indicator
- Visors, padded, Shale-colored, driver and passenger side with cloth trim, extenders, pocket on driver side and vanity mirror on passenger side
- Assist handle, front passenger (Also includes rear outboard passenger assist handle on Extended Cab Models.)
- Coat hook, driver side (Also includes passenger side coat hook on Extended Cab Models.)
- Mechanical
- Engine, Vortec 6000 V8 SFI (300 HP [223.8 kW] @ 4400 rpm, 360 lb.-ft. [486.6 N-m] @ 4000 rpm)
- Cooling, external engine oil cooler, heavy-duty air-to-oil, integral to driver side of radiator tank
- Cooling, internal transmission oil cooler, water-to-oil, integral to driver side of radiator tank (Included and only available with (MT1) Transmission, 4-speed automatic, heavy-duty.)
- Cooling, external transmission oil cooler, auxiliary, heavy-duty air-to-oil (Included and only available with (MT1) Transmission, 4-speed automatic, heavy-duty.)
- Transfer case, electronic Autotrac, includes push-button controls
- Four wheel drive
- Rear axle, 3.73 ratio
- Battery, heavy-duty, 600 cold-cranking amps, includes rundown protection and retained accessory power
- Alternator, 105 amps
- Pickup bed, Fleetside box
- Frame, ladder type
- Recovery hooks, 2 front, frame-mounted
- GVWR, 8600 lbs. (3901 kg) (must specify)
- Suspension Package, Handling/Trailering, heavy-duty
- Suspension, front, independent torsion bar, and stabilizer bar
- Suspension, rear, semi-elliptic 2-stage multi-leaf springs
- Wheels, 4 - 16" x 6.5" (40.6 cm x 16.5 cm) 8-lug polished forged aluminum, includes chrome center caps and steel spare
- Tire carrier, outside spare, winch-type mounted under frame at rear
- Steering, power
- Exhaust, aluminized stainless-steel muffler and tailpipe
- Tools, mechanical jack and wheel wrench, spare tire assist hook, floor-mounted in back of cab
- Chassis
- Frame
- Frame Type: Ladder
- Tires
- Spare Tire Order Code: QIZ
- Front Tire Size: LT245/75R16
- Rear Tire Size: LT245/75R16
- Spare Tire Size: LT245/75R16
- Front Tire Capacity: 2205 lbs
- Rear Tire Capacity: 3042 lbs
- Spare Tire Capacity: 2205 lbs
- Revolutions/Mile @ 45 mph - Front: - TBD - Rev/Mile
- Revolutions/Mile @ 45 mph - Rear: - TBD - Rev/Mile
- Revolutions/Mile @ 45 mph - Spare: - TBD - Rev/Mile
- Brakes
- Brake Type: Pwr
- Brake ABS System: Four-Wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness: 12.8 x 1.5 in
- Rear Brake Rotor Diam x Thickness: 13 x 1.4 in
- Wheels
- Front Wheel Size: 16 x 6.5 in
- Rear Wheel Size: 16 x 6.5 in
- Spare Wheel Size: 16 x 6.5 in
- Front Wheel Material: Aluminum
- Rear Wheel Material: Aluminum
- Spare Wheel Material: Steel
- Steering
- Steering Type: Pwr
- Steering Ratio (:1), On Center: 14.2
- Turning Diameter - Curb to Curb: 48.4 ft
- Turning Diameter - Wall to Wall: - TBD - ft
- Fuel Tank
- Fuel Tank Capacity, Approx: 26 gal
- Fuel Tank Location: LH
- Suspension
- Suspension Type - Front: Torsion Bar
- Suspension Type - Rear: 2-Stage Multi-Leaf
- Spring Capacity - Front: 4500 lbs
- Spring Capacity - Rear: 6000 lbs
- Axle Type - Front: 8-Bolt
- Axle Type - Rear: Semi-Floating
- Axle Capacity - Front: 4500 lbs
- Axle Capacity - Rear: 6000 lbs
- Shock Absorber Diameter - Front: 36 mm
- Shock Absorber Diameter - Rear: 36 mm
- Stabilizer Bar Diameter - Front: 1.42 in
- Trailering
- Dead Weight Hitch - Max Trailer Wt.: 5000 lbs
- Dead Weight Hitch - Max Tongue Wt.: 500 lbs
- Wt Distributing Hitch - Max Trailer Wt.: 10300 lbs
- Wt Distributing Hitch - Max Tongue Wt.: 1500 lbs
- Fifth Wheel Hitch - Max Trailer Wt.: 10300 lbs
- Fifth Wheel Hitch - Max Tongue Wt.: 2500 lbs
- Weight Information
- Gross Axle Wt Rating - Front: 4410 lbs
- Gross Axle Wt Rating - Rear: 6000 lbs
- Curb Weight - Front: 3220 lbs
- Curb Weight - Rear: 2176 lbs
- Gross Vehicle Weight Rating Cap: 8600 lbs
- Frame
- Vehicle
- Vehicle
- Country of Origin: United States Chevrolet Trucks
- Vehicle
- Dimensions
- Exterior Dimensions
- Wheelbase: 143.5 in
- Length, Overall w/o rear bumper: 227.7 in
- Width, Max w/o mirrors: 78.5 in
- Height, Overall: 74.4 in
- Overhang, Front: 36.9 in
- Overhang, Rear w/o bumper: 47.3 in
- Front Bumper to Back of Cab: 138.5 in
- Cab to Axle: 41.9 in
- Cab to End of Frame: - TBD - in
- Ground to Top of Load Floor: 34.6 in
- Ground to Top of Frame: - TBD - in
- Frame Width, Rear: - TBD - in
- Ground Clearance, Front: 7.8 in
- Ground Clearance, Rear: 8.2 in
- Interior Dimensions
- Passenger Capacity: 5
- Front Head Room: 41.0 in
- Front Leg Room: 41.3 in
- Front Shoulder Room: 65.2 in
- Front Hip Room: 61.4 in
- Second Head Room: 38.4 in
- Second Leg Room: 33.7 in
- Second Shoulder Room: 66.3 in
- Second Hip Room: 61.5 in
- Cargo Area Dimensions
- Cargo Box Length @ Floor: 78.7 in
- Cargo Box Width @ Top, Rear: 61.9 in
- Cargo Box Width @ Floor: 64.8 in
- Cargo Box Width @ Wheelhousings: 50.0 in
- Cargo Box (Area) Height: 19.5 in
- Tailgate Width: 61.9 in
- Cargo Volume: 55.6 ft³
- Ext'd Cab Cargo Volume: 49.7 ft³
- Exterior Dimensions
- Powertrain
- Engine
- Engine Order Code: LQ4
- Engine Type: Gas V8
- Displacement: 6.0L/364
- Fuel System: SFI
- SAE Net Horsepower @ RPM: 300 @ 4400
- SAE Net Torque @ RPM: 360 @ 4000
- Engine Oil Cooler: Yes
- Electrical
- Cold Cranking Amps @ 0° F (Primary): 600
- Transmission
- Drivetrain: 4-Wheel Drive
- Trans Order Code: MT1
- Trans Type: 4
- Trans Description Cont.: HD Automatic w/OD
- First Gear Ratio (:1): 2.48
- Second Gear Ratio (:1): 1.48
- Third Gear Ratio (:1): 1.00
- Fourth Gear Ratio (:1): 0.75
- Reverse Ratio (:1): 2.08
- Transfer Case Model: New Venture 261HD
- Transfer Case Gear Ratio (:1), High: 1.00
- Transfer Case Gear Ratio (:1), Low: 2.72
- Engine
- Safety
- Safety features
- Daytime Running Lights
- Automatic Headlights
- Integrated Turn Signal Mirrors
- Tow Hooks
- Air bag - frontal
- Driver Air Bag
- Passenger Air Bag
- Passenger Air Bag Sensor
- Safety features
- Chassis
- Brakes
- ABS
- 4-Wheel Disc Brakes
- Wheels
- Aluminum Wheels
- Steering
- Power Steering
- Brakes
- Seating
- Seats
- Power Driver Seat
- Power Passenger Seat
- Bucket Seats
- Heated Front Seat(s)
- Driver Adjustable Lumbar
- Passenger Adjustable Lumbar
- Seat Memory
- Rear Bench Seat
- Seat trim
- Leather Seats
- Seats
- Exterior
- Tire - spare
- Conventional Spare Tire
- Tire - spare
- Powertrain
- Fuel
- Gasoline Fuel
- Engine
- 8 Cylinder Engine
- Drivetrain
- Four Wheel Drive
- Transmission
- 4-Speed A/T
- A/T
- Transmission Overdrive Switch
- Fuel
- Accessories
- Audio
- AM/FM Stereo
- CD Changer
- CD Player
- Premium Sound System
- Locks
- Keyless Entry
- Power Door Locks
- Window
- Rear Defrost
- Power Windows
- Privacy Glass
- Mirrors
- Heated Mirrors
- Power Mirror(s)
- Auto-Dimming Rearview Mirror
- Passenger Vanity Mirror
- Power Folding Mirrors
- Floor mats
- Floor Mats
- Convenience
- Security System
- Cruise Control
- Adjustable Steering Wheel
- Intermittent Wipers
- Fog Lamps
- Steering Wheel Audio Controls
- Power Outlet
- Immobilizer
- Front Reading Lamps
- Leather Steering Wheel
- Telematics
- Air conditioning
- Climate Control
- Multi-Zone A/C
- A/C
- Audio
- Warranty
- Basic Years: 3
- Basic Miles/km: 36,000
- Drivetrain Years: 3
- Drivetrain Miles/km: 36,000
- Corrosion Years: 6
- Corrosion Miles/km: 100,000
- Roadside Assistance Years: 3
- Roadside Assistance Miles/km: 36,000
- Crash Test Results
- Frontal Driver: * * * *
- Frontal Passenger: * * *
- Side Driver: No Test
- Side Rear Passenger: No Test
- Crash Test Note: Results based on a 35 MPH frontal crash and 38.5 MPH side crash. Results are reported in a range of one to five stars, with five stars indicating the best crash protection for vehicles within the same weight class. This test used driver and passenger belts and airbags.
- NHTSA Rollover Rating: * * * *
- Rollover Note: The Rollover Resistance Rating is an estimate of your risk of rolling over if you have a single vehicle crash. It does not predict the likelihood of that crash. The Rollover Resistance Rating utilizes a "fishhook" maneuver which is a series of abrupt turns at varying speeds to see how "top-heavy" a vehicle is. The more "top-heavy" the vehicle, the more likely it is to roll over. The lowest rated vehicles (1-star) are at least four times more likely to roll over than the highest rated vehicles (5-stars).
