- Factory Options
- METALLIC PAINT
- Safety
- Driver/front passenger airbags
- 3-point seat belts at outboard positions & center lap belt
- Front adjustable shoulder belt anchors at outboard positions
- Front seat belt pretensioners & force limiters
- Child restraint system lower anchors on rear outboard seats
- Rear door child safety locks
- Side-door impact beams
- Exterior
- Black painted rear bumper
- Front/rear mudguards
- Aerodynamic multi-reflector halogen headlamps
- Rear center high-mounted stop lamp
- (4) full-size doors
- Black manual remote mirrors
- Tinted windshield glass
- Variable intermittent windshield wipers
- Interior
- 60/40 split-folding rear bench seat w/outboard adjustable headrests
- Fabric seat trim
- Sculpted door trim w/cloth inserts, dual armrests, map pockets
- Full carpeting
- Center console-inc: dual covered storage, dual front/rear cup holders
- Tilt steering wheel
- Instrumentation-inc: coolant temp, warning lights
- Tachometer
- Rear seat heat ducts
- Dual auxiliary pwr outlets
- Mechanical
- 3.4L DOHC EFI 24-valve V6 engine
- Rear wheel drive
- 3.91 axle ratio
- HD battery (2003)
- Skid plates-inc: front suspension, transfer case, fuel tank
- 121.9" wheelbase
- 5.1' double-wall box
- 5100# GVWR
- Front tow hook
- Independent coil-spring double-wishbone front suspension w/gas-filled shock absorbers
- Rear leaf-spring suspension w/staggered gas-filled shock absorbers
- Front stabilizer bar
- P225/75R15 mud + snow tires
- Full-size spare tire
- Pwr rack & pinion steering
- Pwr ventilated front disc/rear drum brakes w/rear load-sensing proportioning valve
- 18.5 gallon fuel tank
- Chassis
- Frame
- Frame Type: Ladder
- Tires
- Front Tire Capacity: - TBD - lbs
- Rear Tire Capacity: - TBD - lbs
- Spare Tire Capacity: - TBD - lbs
- Brakes
- Brake Type: Pwr-Assisted
- Brake ABS System: Four-Wheel
- Disc - Front (Yes or ): Yes
- Front Brake Rotor Diam x Thickness: 9.9 x 0.87 in
- Drum - Rear (Yes or ): Yes
- Rear Drum Diam x Width: 10.0 x - TBD - in
- Steering
- Steering Type: Pwr Rack & Pinion
- Steering Ratio (:1), On Center: 19.4
- Steering Ratio (:1), At Lock: 3.5
- Turning Diameter - Curb to Curb: 40.0 ft
- Turning Diameter - Wall to Wall: - TBD - ft
- Fuel Tank
- Fuel Tank Capacity, Approx: 18.5 gal
- Fuel Tank Location: Midship
- Suspension
- Suspension Type - Front: Double-Wishbone
- Suspension Type - Rear: Leaf Spring
- Spring Capacity - Front: - TBD - lbs
- Spring Capacity - Rear: - TBD - lbs
- Axle Type - Front: Hypoid
- Axle Type - Rear: Hypoid
- Axle Capacity - Front: - TBD - lbs
- Axle Capacity - Rear: - TBD - lbs
- Stabilizer Bar Diameter - Front: 1.06 in
- Trailering
- Wt Distributing Hitch - Max Trailer Wt.: N/A lbs
- Wt Distributing Hitch - Max Tongue Wt.: N/A lbs
- Fifth Wheel Hitch - Max Trailer Wt.: - TBD - lbs
- Fifth Wheel Hitch - Max Tongue Wt.: - TBD - lbs
- Weight Information
- Gross Axle Wt Rating - Front: - TBD - lbs
- Gross Axle Wt Rating - Rear: - TBD - lbs
- Curb Weight - Front: 1911 lbs
- Curb Weight - Rear: 1564 lbs
- Gross Vehicle Weight Rating Cap: 5100 lbs
- Gross Combined Wt Rating: 9000 lbs
- Frame
- Vehicle
- Vehicle
- Country of Origin: United States Toyota Trucks
- Vehicle
- Dimensions
- Exterior Dimensions
- Wheelbase: 121.9 in
- Length, Overall w/o rear bumper: 202.9 in
- Width, Max w/o mirrors: 70.3 in
- Overhang, Front: 32.3 in
- Overhang, Rear w/o bumper: 43.1 in
- Front Bumper to Back of Cab: - TBD - in
- Cab to Axle: - TBD - in
- Cab to End of Frame: - TBD - in
- Ground to Top of Load Floor: - TBD - in
- Ground to Top of Frame: - TBD - in
- Frame Width, Rear: - TBD - in
- Interior Dimensions
- Front Head Room: 38.8 in
- Front Leg Room: 42.8 in
- Front Shoulder Room: 53.9 in
- Front Hip Room: 49.6 in
- Second Head Room: 37.7 in
- Second Leg Room: 33.7 in
- Second Shoulder Room: 53.5 in
- Second Hip Room: 50.8 in
- Cargo Area Dimensions
- Cargo Box Length @ Floor: 61.5 in
- Cargo Box Width @ Top, Rear: 57.9 in
- Cargo Box Width @ Floor: 57.9 in
- Cargo Box Width @ Wheelhousings: 40.9 in
- Cargo Box (Area) Height: 15.9 in
- Tailgate Width: - TBD - in
- Cargo Volume: - TBD - ft³
- Ext'd Cab Cargo Volume: - TBD - ft³
- Exterior Dimensions
- Powertrain
- Engine
- Engine Type: Gas V6
- Displacement: 3.4L/208
- Fuel System: EFI
- SAE Net Horsepower @ RPM: 190 @ 4800
- SAE Net Torque @ RPM: 220 @ 3600
- Electrical
- Cold Cranking Amps @ 0° F (Primary): - TBD -
- Maximum Alternator Capacity (amps): 70
- Maximum Alternator Watts: 1050
- Transmission
- Drivetrain: Rear Wheel Drive
- Trans Type: 4
- Trans Description Cont.: Automatic w/OD
- First Gear Ratio (:1): 2.804
- Second Gear Ratio (:1): 1.531
- Third Gear Ratio (:1): 1.000
- Fourth Gear Ratio (:1): 0.705
- Reverse Ratio (:1): 2.393
- Trans Power Take Off: - TBD -
- Trans PTO Access: - TBD -
- Transfer Case Power Take Off: - TBD -
- Cooling System
- Total Cooling System Capacity: 10.0 qts
- Engine
- Safety
- Safety features
- Child Safety Locks
- Tow Hooks
- Air bag - frontal
- Driver Air Bag
- Passenger Air Bag
- Passenger Air Bag On/Off Switch
- Safety features
- Chassis
- Brakes
- ABS
- Front Disc/Rear Drum Brakes
- Steering
- Power Steering
- Brakes
- Seating
- Seats
- Pass-Through Rear Seat
- Bucket Seats
- Rear Bench Seat
- Seat trim
- Cloth Seats
- Seats
- Exterior
- Doors
- Third Passenger Door
- Fourth Passenger Door
- Tire - rear
- Tires - Rear On/Off Road
- Tire - front
- Tires - Front On/Off Road
- Tire - spare
- Conventional Spare Tire
- Doors
- Powertrain
- Fuel
- Gasoline Fuel
- Engine
- V6 Cylinder Engine
- Drivetrain
- Rear Wheel Drive
- Transmission
- 4-Speed A/T
- A/T
- Fuel
- Accessories
- Audio
- AM/FM Stereo
- Cassette
- Convenience
- Adjustable Steering Wheel
- Intermittent Wipers
- Variable Speed Intermittent Wipers
- Power Outlet
- Front Reading Lamps
- Audio
- Warranty
- Basic Years: 3
- Basic Miles/km: 36,000
- Drivetrain Years: 5
- Drivetrain Miles/km: 60,000
- Corrosion Years: 5
- Corrosion Miles/km: Unlimited
- Crash Test Results
- Frontal Driver: * * * *
- Frontal Passenger: * * * *
- Side Driver: * * * * *
- Side Rear Passenger: * * * * *
- Crash Test Note: Results based on a 35 MPH frontal crash and 38.5 MPH side crash. Results are reported in a range of one to five stars, with five stars indicating the best crash protection for vehicles within the same weight class. This test used driver and passenger belts and airbags.
