- Factory Options
- PAINT, SOLID
- ENGINE, VORTEC 4300 V6 MFI(195 HP [145.4 kW] @ 4600 rpm, 260 lb.-ft. [351.0 N-m] @ 2800 rpm)
- Safety
- Air bags, frontal, driver and right front passenger, includes Passenger Sensing System (Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owners Manual for more safety information)
- Exterior
- Paint, solid
- Bumper, front, chrome, with Gray lower
- Bumper, rear, painted step, includes pad
- Air dam, Gray
- Grille, Gray surround, with chrome accent bar
- Lamps, dual cargo area lamps
- Mirrors, outside rearview, foldaway, manual, Black, adjustable
- Glass, Solar-Ray light tinted, all windows
- Wipers, intermittent, front, wet-arm with pulse washers
- Interior
- Floor covering, rubberized vinyl, Black
- Steering column, Tilt-Wheel, adjustable, includes brake/transmission shift interlock
- Steering wheel, includes theft-deterrent locking feature
- Theft-deterrent system, PASSlock II
- Instrumentation, analog, includes speedometer, odometer with trip odometer, fuel level, voltmeter, engine temperature, oil pressure and tachometer
- Driver Information Center, monitors numerous systems depending on vehicle equipment
- Warning tones, headlamp on, key-in-ignition, driver and passenger buckle up reminder, turn signal on
- Sound system feature, 4-speakers
- Cupholders, front (Also includes rear cupholders on Extended and Crew Cab Models)
- Cigarette lighter, on instrument panel
- Mirror, inside rearview, manual day/night
- Visors, padded, Shale-colored, driver and passenger side with cloth trim, extenders, pocket on driver side and vanity mirror on passenger side
- Assist handle, front passenger (Also includes outboard rear assist handle on Extended or Crew Cab Models.)
- Coat hook, driver side (Also includes passenger side coat hook on Extended and Crew Cab Models.)
- Mechanical
- Engine, Vortec 4300 V6 MFI (195 HP [145.4 kW] @ 4600 rpm, 260 lb.-ft 351.0 N-m] @ 2800 rpm) (Required and standard on C*15703, C*15903, and CC15753 Models only. - Not available with (VYU) Snow Plow Prep Package or (Z82) Trailering equipment, heavy-duty.)
- Rear wheel drive
- Battery, heavy-duty, 600 cold-cranking amps, includes rundown protection and retained accessory power
- Alternator, 145 amps
- Recovery hooks, front, frame-mounted
- Frame, ladder-type, hydroformed
- Pickup bed, Fleetside box
- GVWR, 6100 lbs. (2767 kg) (Requires CC15703 Models)
- Suspension Package, Solid Smooth Ride, includes 35mm piston twin tube shocks (Not available with (PDU) Light Duty Power Package)
- Suspension, front, independent (2WD Models include coil springs. - 4WD Models include torsion bars.)
- Suspension, rear, semi-elliptic 2-stage multi-leaf springs
- Wheels, 4 - 17" x 7" (43.2 cm x 17.8 cm) 6-lug steel, painted, includes painted center caps and steel spare
- Tire carrier, outside spare, winch-type mounted under frame at rear
- Steering, power
- Exhaust, aluminized stainless-steel muffler and tailpipe
- Tools, mechanical jack and wheel wrench, spare tire assist hook, floor-mounted in back of cab
- Chassis
- Frame
- Frame Type: Ladder
- Tires
- Front Tire Size: P245/70R17
- Rear Tire Size: P245/70R17
- Spare Tire Size: P245/70R17
- Front Tire Capacity: - TBD - lbs
- Rear Tire Capacity: - TBD - lbs
- Spare Tire Capacity: - TBD - lbs
- Brakes
- Brake Type: Hydraulic
- Brake ABS System: 4-Wheel
- Disc - Front (Yes or ): Yes
- Front Brake Rotor Diam x Thickness: 11.8 x 1.18 in
- Drum - Rear (Yes or ): Yes
- Rear Drum Diam x Width: 11.6 x 2.4 in
- Wheels
- Front Wheel Size: 17 x 7.5 in
- Rear Wheel Size: 17 x 7.5 in
- Spare Wheel Size: 17 x 7.5 in
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Spare Wheel Material: Steel
- Steering
- Steering Type: Pwr
- Steering Ratio (:1), On Center: 14.2
- Steering Ratio (:1), At Lock: - TBD -
- Turning Diameter - Curb to Curb: 40.1 ft
- Turning Diameter - Wall to Wall: - TBD - ft
- Fuel Tank
- Fuel Tank Capacity, Approx: 26 gal
- Fuel Tank Location: LH
- Suspension
- Suspension Type - Front: Coil Spring
- Suspension Type - Rear: 2-Stage Multi-Leaf
- Spring Capacity - Front: 3476 lbs
- Spring Capacity - Rear: 3686 lbs
- Axle Type - Front: Independent
- Axle Type - Rear: Semi-Floating
- Axle Capacity - Front: 3150 lbs
- Axle Capacity - Rear: 3750 lbs
- Stabilizer Bar Diameter - Front: 1.42 in
- Stabilizer Bar Diameter - Rear: - TBD - in
- Trailering
- Dead Weight Hitch - Max Trailer Wt.: 5000 lbs
- Dead Weight Hitch - Max Tongue Wt.: 750 lbs
- Weight Information
- Gross Axle Wt Rating - Front: 3150 lbs
- Gross Axle Wt Rating - Rear: 3686 lbs
- Curb Weight - Front: 2400 lbs
- Curb Weight - Rear: 1682 lbs
- Gross Vehicle Weight Rating Cap: 6100 lbs
- Frame
- Vehicle
- Vehicle
- Country of Origin: United States Chevrolet Trucks
- Vehicle
- Dimensions
- Exterior Dimensions
- Wheelbase: 119.0 in
- Length, Overall w/o rear bumper: 205.7 in
- Width, Max w/o mirrors: 78.5 in
- Height, Overall: 71.2 in
- Overhang, Front: 36.9 in
- Overhang, Rear w/o bumper: 47.0 in
- Front Bumper to Back of Cab: 114.0 in
- Cab to Axle: 41.9 in
- Cab to End of Frame: - TBD - in
- Ground to Top of Load Floor: 31.6 in
- Ground to Top of Frame: - TBD - in
- Frame Width, Rear: - TBD - in
- Ground Clearance, Front: 8.0 in
- Ground Clearance, Rear: 8.5 in
- Interior Dimensions
- Passenger Capacity: 3
- Front Head Room: 41.0 in
- Front Leg Room: 41.3 in
- Front Shoulder Room: 65.2 in
- Front Hip Room: 61.4 in
- Cargo Area Dimensions
- Cargo Box Length @ Floor: 78.7 in
- Cargo Box Width @ Floor: 64.8 in
- Cargo Box Width @ Wheelhousings: 50.0 in
- Cargo Box (Area) Height: 19.5 in
- Tailgate Width: 63.8 in
- Cargo Volume: 56.9 ft³
- Exterior Dimensions
- Powertrain
- Engine
- Engine Order Code: LU3
- Engine Type: Gas V6
- Displacement: 4.3L/262
- Fuel System: MFI
- SAE Net Horsepower @ RPM: 195 @ 4600
- SAE Net Torque @ RPM: 260 @ 2800
- Electrical
- Cold Cranking Amps @ 0° F (Primary): 600
- Transmission
- Drivetrain: Rear Wheel Drive
- Engine
- Safety
- Safety features
- Daytime Running Lights
- Automatic Headlights
- Tow Hooks
- Air bag - frontal
- Driver Air Bag
- Passenger Air Bag
- Passenger Air Bag Sensor
- Safety features
- Chassis
- Brakes
- ABS
- Front Disc/Rear Drum Brakes
- Wheels
- Steel Wheels
- Steering
- Power Steering
- Brakes
- Exterior
- Tire - rear
- Tires - Rear All-Season
- Tire - front
- Tires - Front All-Season
- Tire - rear
- Powertrain
- Fuel
- Gasoline Fuel
- Engine
- V6 Cylinder Engine
- Drivetrain
- Rear Wheel Drive
- Fuel
- Accessories
- Mirrors
- Passenger Vanity Mirror
- Convenience
- Adjustable Steering Wheel
- Intermittent Wipers
- Power Outlet
- Immobilizer
- Front Reading Lamps
- Mirrors
- Warranty
- Basic Years: 3
- Basic Miles/km: 36,000
- Drivetrain Years: 3
- Drivetrain Years: 5
- Drivetrain Miles/km: 100,000
- Drivetrain Miles/km: 36,000
- Corrosion Years: 6
- Corrosion Miles/km: 100,000
- Roadside Assistance Years: 3
- Roadside Assistance Miles/km: 36,000
